The Wunder Bar Mechanical Flex Hose bar dispenser is available in 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, and 14
button models. All models can be configured for many combinations of carbonated, non-carbonated, non-
carbonated premix and energy drink products at any time. All of these combinations are field-convertible and
can be modified without shutting off the dispenser. All seven, eight, and nine button dispensers have all the
necessary valves and product tubes already installed into the dispenser, making the upgrade to up to ten
buttons as easy as adding buttons on the handle and input modules and input fittings at the manifold.
BUTTONS AND BUTTERFLY PLATES
_' ,'-
The buttons and button plate can be removed while dispenser is under pressure. After the button plate has
been removed, buttons can be changed as can the configuration of the dispenser. By removing the butterfly
retainer and screws, and lifting out the butterfly plates, various standard configurations and endless special
configurations can be created. The butterfly plates’ balls fit into indentations in the o-ring retainers located in
the handle recess. The half moon cut out area of the butterfly plates are where the retainer and retainer
screws are located when attaching the plates to the handle. When replacing butterfly plates, be careful not
to over-tighten the retainer screws. Over-tightening the retainer screws can cause the butterfly plates to
bind. See the Butterfly Plate Maps on pages 10 and 11 of this manual.
EXPLANATION OF MODEL NUMBERS
',_ _ _
POST-MIX AND ENERGY DRINK DISPENSERS
POST-MIX JUICE DISPENSERS
M4 - a b c d e f g h (-N)
Mark 4
Dispenser
Total Number
of Buttons
1 to 14
Number of
Carbonated
Products
Number of
Non-Carbonated
Products
Number of
Non-Carbonated
Pre-Mix Products
Color
K = Black
R = Red
B = Blue
G = Green
C = Cabana
Blue
Dispenser Type::
S = Standard (Series 2.5)
2 = Series II
3 = Series III
(large Soda/Water tubing)
Manifold Type:
M = Metering Screws
F = Flow Regulated
FM = Flow Regulated
& Metering Screws
Applies to NSF
listed only
(with plastic sheathing)
MARK 4 MANUAL
Length:
3 = 3 feet
4 = 4 feet
5 = 5 feet
6 = 6 feet
Total
Number
of Buttons
6 to 12
Juice
Dispenser
Mark 4
Dispenser
Color
K = Black
R = Red
B = Blue
G = Green
C = Cabana
Blue
Dispenser Type::
S = Standard (Series 2.5)
2 = Series II
3 = Series III (large Soda/Water tubing
M4 - a JD e f h (-N)
Applies to NSF
listed only
(with plastic sheathing)
Length:
3 = 3 feet
4 = 4 feet
5 = 5 feet
6 = 6 feet
www.wunderbar.com
Note: Juice dispensers are available
with Metering Screws, only.
