WUNDER SA.BI. SRL MANUALE ISTRUZIONI
REV. 00 del 20/10/2010 3
ct
400.00/0.05 500.00/0.05
750.00/0.05 999.95/0.05 999.95/0.05
gn
1234.6/0.2 1543.2/0.2
2314.8/0.2 3086.4/0.2 4629.6/0.2
dwt
51.44/0.01 64.30/0.01
96.45/0.01 128.60/0.01 192.90/0.01
ozt
2.5720/0.0005 3.2150/0.0005
4.8225/0.005 6.4300/0.0005 9.9995/0.0005
Mod. 500AX
20A 20B 10A
g
500/0.01
20/0.001g 20/0.002g 10/0.001g
oz
17.636/0.001
/
Readability: 0.1 g/ 0.005 oz/0.5 ct/1 grain/0.1 dwt/0.005 ozt
0.05 g/0.002 oz/0.5 ct/1 grain/0.05 dwt/0.002 ozt
0.02 g/0.001 oz/0.1 ct/0.5 grain/0.02 dwt/0.001 ozt
0.01 g/0.0005 oz/0.05 ct/0.2 grain/0.01dwt/0.0005 ozt
0.001 g/0.005 ct/ 0.02 gn/0.001 dwt
0.002 g/0.01 ct/0.05 gn/0.002 dwt
Units (default): 4 units available
4. INSTALLATION
After having removed the scale from the package, check the integrity of all components.
The scale must be placed far from heaters and other electronic devices, in a room free from excessive vibrations and draughts.
The working temperature must be included between 10°C and 30°C.
Always allow the scale to acclimate to normal room temperature for at least one hour before use.
5. USE INSTRUCTIONS
WEIGHING
Press ON/OFF key to switch on and wait until it displays “0.0”. Put the object(s)on the weighing tray.
Automatically switch off after 30 seconds or press ON/OFF key when display “zero” to switch off.
TARE WEIGHING
Turn on scale as described above. Place the “tare item” on the tray and press TARE key. Wait until “0.0” and “Zero” is displayed
and add the “net-weight-item”
CALIBRATION
(REMARK: For MINI Series, “MODE” button is also “UCAL” button.)
Press ON/OFF key to switch on and wait until it displays “0.0”, press and hold “UCAL” key until display “CAL” to enter calibration
status, display “0.0” afterwards. Press “UCAL” to calibrate zero point. Wait till 2-3 seconds, on LCD shows a weight reading and
put the named weight on the platform, wait till 3 seconds and the LCD panel shows “PASS” then auto power off. (If it shows
