Symbols, abbreviations and terms used
Symbol, character Explanation
General prohibition sign. This action is forbidden!
Do not touch the rotating parts of the power tool.
Observe the instructions in the text or graphic opposite!
Make sure to read the enclosed documents such as the Instruction Manual and the General
Safety Instructions.
Before commencing this working step, pull the mains plug out of the socket. Otherwise there
will be danger of injury if the power tool should start unintentionally.
Use eye-protection during operation.
Use ear protection during operation.
Use protective gloves during operation.
An exposed surface is very hot if touched and therefore dangerous.
Additional information.
This sign indicates a possible dangerous situation that could cause severe or fatal injury.
Confirms the conformity of the power tool with the directives of the European Community.
Worn out power tools and other electrotechnical and electrical products should be sorted
separately for environment-friendly recycling.
Product with double or reinforced insulation
Ø Diameter of a round part
Ø
D
=Max. diameter of diamond wheel
Weight according to EPTA-Procedure 01/2003
Character Unit of measure,
international
Unit of measure,
national
Explanation
n /min rpm Rated speed
P
1
W W Power input
P
2
W W Output
f Hz Hz Frequency
M… mm mm Size of metric thread
L
wA
dB dB Sound power level
L
pA
dB dB Sound pressure level
L
pCpeak
dB dB Peak sound pressure level
K… Uncertainty
m/s
2
m/s
2
Acceleration/Vibrational emission
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
min, m/s
2
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
min, m/s
2
Basic and derived units of measure from the
international system of units
SI.
WARNING
