18
End the measurement by pressing the push-
button. The greatest, the shortest and the last
measured distance are indicated in the display.
Memory of Parameters
Any measure of distance, area or volume can
be stored temporarily and recalled again:
Carry out a distance measurement.
Press and hold the button until a beep confirms
that the measurement is stored.
The stored value can be recalled any time by
pressing the button again.
Memory of Measured Values
Press button twice to recall the last 20 deter-
mined measured values in reverse order.
Use the and buttons for
navigating.
Press the button to use the displayed meas-
uring value for a calculation.
To delete the measuring value memory, press
buttons and at the same time.
Measuring Functions
Addition/Subtraction
– Measure a distance.
– Press button or .
– Measure a 2. distance.
– Press button .
The two measured values and the result are indi-
cated.
Area Measurement
– Pres the button briefly. The area symbol
appears on the display and the laser is acti-
vated.
– Press pushbutton and take the first length
measurement (e. g. length).
– Press pushbutton and take the second
length measurement (e. g. width).
The two measured values and the resulting area
are indicated in the display.
☞ The area measure is correct only when
the measurements have been taken at a
right angle to each other.
Volume Measurement
– Press pushbutton. The volume symbol
appears on the display and the laser is
switched on.
– Press pushbutton and take the first length
measurement (e. g. length).
– Press pushbutton and take the second
length measurement (e. g. width).
– Press pushbutton and take the third
length measurement (e. g. height).
The three measured values and the resulting vol-
ume are indicated in the display.
☞ The volume measure is correct only when
the measurements have been taken at a
right angle to each other.
Measuring Inclinations
– While measuring, hold the device as level as
possible (lateral inclination ±10°) with the
display facing upward.
– Press button briefly. The symbol
appears on the display. The current inclina-
tion angle is indicated in “°” or “%”, depend-
ing on the setting.
– Activate the laser with button and align
it for measuring the inclination.
– Press button and measure the angle.
The measured angle and the distance appear
on the display.
Measuring Inclinations and
Horizontal Distances
– Press button twice. The symbol
appears on the display.
– Press button . The measured angle, the
distance and the resulting calculated hori-
zontal distance appear on the display.
After the measurement, the device returns to the
distance mode.
WDM 101 - Buch Seite 18 Dienstag, 8. Januar 2008 1:36 13
