20
The auxiliary measurements and result l
1
are
indicated in the display.
Automatic Release (Timer)
The automatic release can be used when meas-
uring and holding the target plate at the same
time is required.
– Press pushbutton briefly to start a 5 second
countdown.
– By pressing buttons , the countdown
can be prolonged to 60 seconds.
The countdown starts immediately after releas-
ing the button or, when the laser was not acti-
vated, after pressing button .
Each of the last 5 seconds is indicated acousti-
cally.
Determining a Solid Angle
The angle in a triangle can be calculated by
measuring the three sides. This function, as an
example, can be used for checking α
right-angled solid angle α.
– Press pushbutton until the symbol
appears in the display. Mark the marking
point right and left of the angle to be meas-
ured.
– Position the device on each side respectively,
press the pushbutton and measure both
of the short distances (d
1
, d
2
) one after
another.
– Position the device, press the pushbutton
and measure the long distance (d
3
).
The auxiliary measurements and result are indi-
cated in the display.
Maintenance and Cleaning
❏ Do not use aggressive cleaning agents; use a
soft, moist cloth.
❏ Clean the optics using a cleaning cloth for
glasses or lenses.
❏ Do not attempt to open the device.
If the machine should happen to fail despite the
care taken in manufacture and testing, repair
should be carried out by an authorized cus-
tomer service agent for Würth power tools.
For all correspondence and spare parts orders,
always include the article number on the type
plate of the machine.
For the current spare parts list of this machine,
log into the Internet under “http://
www.wuerth.com/partsmanager” or ask for a
copy at your nearest Würth branch office.
Trouble Shooting/Corrective Action
F
Indication Cause Corrective Action
156 Lateral inclination greater than 10° Hold device level (not laterally inclined)
160 Angle value too large Measure angles to 45 ° max.
204 Calculation error Conflict of units: Lengths miscalculated with areas
and volume
252/253 Temperature not within the permitted range Allow tool to cool down/warm up
255 Receive signal too weak, Measuring period too
long, distance longer than 100 m
Use target plate (accessory)
256 Receive signal too strong Use target plate (accessory)
257 Measuring error, ambient light too bright Carry out measurement under other light condi-
tions
260 Laser beam was interrupted during measure-
ment
Repeat measurement
Hardware error Switch the tool off and on again; if required, sev-
eral times. If the error symbol does not go out, con-
tact Würth customer service agent.
WDM 101 - Buch Seite 20 Dienstag, 8. Januar 2008 1:36 13
