X-plode PFX-2000 User Manual

asdasdasdasd
asdasdasd
Item
Qty
Description
1
1
Ground frame
2
2
Guide bar
3
1
Weight stack
4
2
Back support tube
5
6
Outer hexagon bolt (10mm x 65mm)
6
32
Washer (10mm)
7
8
Outer hexagon bolt (10mm x 20mm)
8
2
Rubber mat
9
2
Outer hexagon bolt (8 mm x 70mm)
10
2
Lock nut (8mm)
11
1
Side support frame
12
1
Up frame
13
2
Fixing plate
14
1
Shield support frame
15
11
Nut (10mm)
16
6
Outer hexagon bolt (12mm x 70mm)
17
22
Washer (12mm)
18
11
Nut (12mm)
19
6
Outer hexagon bolt (10mm x 125mm)
20
2
Outer hexagon bolt (10mm x 16mm)
21
1
Seat
22
1
Seat adjustment frame
23
1
Decorative plate (right)
24
1
Decorative plate (left)
25
4
Pulley spacer sleeve
26
1
Adapter sleeve
27
1
Leg lift bending tube
28
4
Pulley
29
1
Leg extension turning axle
30
3
Outer hexagon bolt (12mm x 130mm)
31
2
Outer hexagon bolt (10mm x 130mm)
32
1
Right pec fly arm
33
1
Left pec fly arm
34
2
Handle
35
1
Front push frame
36
1
Front push frame axle
37
1
Front push arm
38
1
Front push arm link axle
39
1
Arc plate
40
6
Washer (25mm x 10mm)
41
1
Pulley supprt frame
42
2
Hexagon socket button head screws
43
9
Outer hexagon bolt (8mm x 16mm)
44
13
Washer (8mm)
45
2
Shape pulley frame
46
1
Cable #1
47
1
Double puley plate
48
1
Cable #2
49
1
Cable #3
50
1
Cable #4
51
2
Sheild
52
1
Seat
53
1
Back pad adjustment frame
54
1
Sponge tube
55
1
Lat pulldown handle
56
1
Low pulldown handle
57
1
Feet plate
58
1
Outer hexagon bolt (10mm x 70mm)
59
1
Sponge tube
60
12
Spring washer (8mm)
61
4
Outer hexagon bolt (8mm x 40mm)
62
1
Pad
63
1
Double puley plate
PARTS
2
3
