Xenyx 1202FX User Manual

12
XENYX 1202FX/1002FX
XENYX 1202FX/1002FX Hook-up
(EN)
Step 1: Hook-Up
(ES)
Paso 1: Conexión
(FR)
Etape 1 : Connexions
(DE)
Schritt 1: Verkabelung
(PT)
Passo 1: Conexões
(IT)
Passo 1: Allacciare
(NL)
Stap 1: Hook-Up
(SE)
Steg 1: Anslutning
(PL)
Krok 1: Podłączeni
L
R
XM8500
B215D Active Speakers
Bass Guitar
DI100
F1320D Active Monitors
MP3 PlayerFX2000 Effects Processor Portable
Digital
Recorder

Xenyx 1202FX Specifications

General

Channels	12
Mic Preamps	4
Phantom Power	Yes
EQ Bands	3-band
Type	Analog
Inputs - Other	2 x RCA
USB Interface	No
Effects	Yes
Inputs - Line	8 x 1/4"
Outputs - Other	2 x RCA
Aux Sends Type	Pre/Post
Effects Processor	Yes
Headphone Output	1 x 1/4"
Tape Inputs/Outputs	2 x RCA
