Xerox ColorQube 9303 Service Manual

November 2015
5-63
Xerox® ColorQube® 9303 Family
PL 26.10
Parts Lists
PL 26.10 Consumables and Tools (1 of 2)
Item Part Description
1 008R90176 Cleaning fluid (IPA & water)
(WARNING)
2 – Ethernet crossover cable (PWS to
SBC PWB) (Not spared)
3 600T02261 Finisher bypass connector
4 043E00550 Plastislip grease
5 – Disposable gloves (general
protection- see below for variants)
(Qty. 100) (WARNING)
– 099P03227 Small
– 099P03228 Medium
– 099P03229 Large
– 099P03230 Extra large
6 019P03025 Microfibre cleaning cloth
7 108R00834 Magenta solid ink stick (Metered)
– 108R00830 Magenta solid ink stick (Sold)
– 108R00838 Magenta solid ink stick (Sold DMO)
8 108R00833 Cyan solid ink stick (Metered)
– 108R00829 Cyan solid ink stick (Sold)
– 108R00837 Cyan solid ink stick (Sold DMO)
9 108R00835 Yellow solid ink stick (Metered)
– 108R00831 Yellow solid ink stick (Sold)
– 108R00839 Yellow solid ink stick (Sold DMO)
10 108R00836 Black solid ink stick (Metered)
– 108R00832 Black solid ink stick (Sold)
– 108R00840 Black solid ink stick (Sold DMO)
11 008R90273 Antistatic fluid
12 – Molub grease 777
13 – Cable tie (P/O PL 31.10 Item 12)
14 655N00118 Foreign interface test tool (USSG/
XC)
15 008R12912 Staple cartridge (HVF - 100 sheet)
(1 x 5000)
– 008R12919 Staple cartridge (HVF - 50 sheet)
(1 x 5000)
16 008R12964 Staple cartridge (LCSS) (1 x 5000)
17 050K21270 Staples (HVFBM) (1 x 2000)
– 008R12897 Staples (HVFBM) (8 x 2000)
– 008R12941 Staples (LCSS) (3 x 5000)
– 008R12898 Staples (HVF- 100 sheet) (3 x
5000)
– 008R12920 Staples (HVF - 50 sheet) (3 x
5000)
WARNING
Wear protective gloves, PL 26.10 Item 5 when using
solvents and cleaning agents.
www MK-Electronic de

Xerox ColorQube 9303 Specifications

General

Dimensions (WxDxH)	1398 x 722 x 1156 mm
Networking features	Gigabit Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	print, scan
Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Print speed (color, normal quality, A4/US Letter)	55 ppm
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	300000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Time to first copy (black, normal)	8.2 s
Copy speed (black, normal quality, A4)	60 cpm
Copy speed (color, normal quality, A4)	55 cpm
Scan to	E-mail, FTP, Image, USB
Scan speed (black)	84 ppm
Image formats supported	JPG
Optical scanning resolution	- DPI
Total input capacity	3300 sheets
Total output capacity	- sheets
Maximum input capacity	7300 sheets
Paper tray 2 input capacity	550 sheets
Auto document feeder (ADF) input capacity	100 sheets
Maximum print size	320 x 457 mm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4
Display	-
Control type	Touch
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Internal storage capacity	160 GB
Power consumption (average operating)	- W
Faxing	Mono faxing
