Xerox DocuColor 2240 Service Manual

09/03
6-19
DC 3535/2240/1632, WC M24
715-xxx IIT NVM List
General Procedures and Information
Initial issue
715-247 B/W-Offset for Text/Image DADF Single
Side mode (Real Time AE)
13 0~255 For AE offset data DADF Single Side Document text/photo in B/W model
715-248 B/W-Offset for Text DADF Single Side
mode(Real Time AE)
15 0~255 For AE offset data DADF Single Side Document text in B/W model
715-249 B/W-Offset for Map DADF Single Side
mode Real Time AE)
13 0~255 For AE offset data DADF Single Side Document map in B/W model
715-250 B/W-Offset for Text/Image DADF
Duplex Side mode (Real Time AE)
17 0~255 For AE offset data DADF Duplex Side Document text/photo in B/W model
715-251 B/W-Offset for Text DADF Duplex Side
mode (Real Time AE)
17 0~255 For AE offset data DADF Duplex Side Document text in B/W model
715-252 B/W-Offset for Map DADF Duplex Side
mode (Real Time AE)
17 0~255 For AE offset data DADF Duplex Side Document map in B/W model
715-253 Color-Offset for Text/Image Platen
mode (Real Time AE)
15 0~255 For AE offset data Platen text/photo in Color model
715-254 Color-Offset for Text Platen mode (Real
Time AE)
15 0~255 For AE offset data Platen text in Color model
715-255 Color-Offset for Text Platen mode (Real
Time AE)
15 0~255 For AE offset data Platen map in Color model
715-256 Color-Offset for Text/Image DADF Sin-
gle Side mode (Real Time AE)
17 0~255 For AE offset data DADF Single Side Document text/photo in Color model
715-257 Color-Offset for Text DADF Single Side
mode (Real Time AE)
18 0~255 For AE offset data DADF Single Side Document text in Color model
715-258 Color-Offset for Map DADF Single Side
mode (Real Time AE)
17 0~255 For AE offset data DADF Single Side Document map in Color model
715-259 Color-Offset for Text/Image DADF
Duplex Side mode (Real Time AE)
17 0~255 For AE offset data DADF Duplex Side Document text/photo in Color model
715-260 Color-Offset for Text DADF Duplex Side
mode (Real Time AE)
18 0~255 For AE offset data DADF Duplex Side Document text in Color model
715-261 Color-Offset for Map DADF Duplex
Side mode (Real Time AE)
17 0~255 For AE offset data DADF Duplex Side Document map in Color model
715-300 IIT Fail Bypass 0 0~1 0=Fail Bypass is not available; 1=Fail Bypass is available
715-301 SS Registration Adjustment 100 16~184 Slow Scan Direction Regi Correction Value (0.036mm/step) Adjustment at factory.
715-302 SS Magnification Adjustment 50 44~56 Slow Scan direction Magnification Correction Value (0.1%/step) Adjustment at factory.
715-400 Platen/ADF 1 0~1 0=Platen model 1=ADF model.
715-401 AGOC Timing 15 0~29 Time between Power On/Energy Saver recovery and AGOC (min.) (0=Timer not available)
715-406 Fax Document Size Detection 0 0, 1 0 = metric sizes, 1 = inch sizes
715-800 lIISS/ADF Communication Fail Count
Overall Total
0 0~65535 cumulative Fail Counter (Write not permitted)
715-801 IISS/ADF Communication Fail Count
Since Reset
0 0~65535 cumulative Fail Counter at the previous clearing (Write not permitted)
715-802 lIISS RAM CHECK Failure Count Over-
all Total
0 0~65535 cumulative Fail Counter (Write not permitted)
715-803 IISS RAM CHECK Failure Count Since
Reset
0 0~65535 cumulative Fail Counter at the previous clearing (Write not permitted)
Table 1 Chain 715
Chain-Link Name Default Range Description
