Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 9-17
Parts List
41. -----
42. Shaft Feed
43. -----
44. Support Nudger Assy
45. Shaft Nudger
46. Roll Assy Gear Nudger
47. Gear Idler Nudger
48. Holder No Paper Left A4
49. Actuator No Paper A4
50. Holder No Paper Right A4
51. Clutch Oneway Nudger
52. Clutch Oneway Feed
53. Roll Assy Feed (Periodic Replacement Part - per 100K prints)
(consist of 3 pcs and tech sheet)
675K47670
54. PWBA OHP LED (Not used on 6180MFP)
55. Cover OHP Sensor
56. PWBA OHP Sensor (Not used on 6180MFP)
57. Harness Assy OHP Sensor (J241-J2411, J2412)
58. Harness Assy OHP (J24-P241)
59. Nudger Assy (with 44-50) 068K29482
60. Guide Film
Parts List 3.2 Paper Feeder (2 of 2) (continued)
ID No. Name/Description Part Number

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
