Xerox VersaLink B7025 Service Manual

April 2017
6-49
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC301, dC305
General Procedures and Information
Launch Issue
dC301 NVM Initialization
Purpose
To reset the values of all applicable NVM parameters to default.
Procedure
1. Enter Diagnostics, GP 1.
2. Touch dC301 Initialize NVM.
3. Select the area to be initialized. Refer to Table 1.
4. Touch Start.
5. Follow the UI messages to initialize the NVM.
6. Touch Close to return to the Diagnostics screen.
7. Enter dC131. Ensure NVM value 790-900 is set to 1. If the NVM value had to be changed,
switch off, then switch on the machine, GP 10. Verify that the Embedded Web Server is
working.
8. Exit diagnostics, GP 1.
dC305 UI Panel Diagnostics
Purpose
To test the LED and audio functions of the user interface.
Procedure
1. Enter Diagnostics, GP 1.
2. Touch dC305 UI Panel Diagnostics.
3. Touch LED Test or Audio Test.
4. Exit diagnostics, GP 1.
LED Test
1. Touch the 1 or more LEDs to be diagnosed:
• Interactive
• Error
•NFC
• Power
•Data
2. Touch the display pattern to be diagnosed. The selected LEDs are switched on.
3. Touch All Off.
4. Touch the back button (top left) to return to the Diagnostics screen.
Audio Test
1. Touch Volume. Adjust the volume as necessary.
2. Touch the pattern to be diagnosed. The audio sounds with the specified volume and pat-
tern:
• Pattern 1
• Pattern 2
• Pattern 3
• Pattern 4
• Pattern 5
• Pattern 6
3. Touch the back button (top left) to return to the Diagnostics screen.
Table 1 NVM areas
Area Comments
IOT 1 Drive PWB NVM. After initializing the IOT 1 NVM, ensure the tray module
type is correctly set, refer to the 077-211 Tray Module Mismatch RAP.
IOT 2 Do not use.
Finisher Integrated finisher or LX office finisher NVM.
IFM Do not use.
IISS - IIT/IPS Scanner NVM.
IISS - Extension Do not use.
Input Device DADF NVM.
Sys - System ESS PWB NVM.
Sys - User SD card customer settings. The installation wizard will have to be run
after initializing the SD card NVM.
Fault Counter Fault history.
HCS 1 Do not use.
HCS 2 Do not use.
PFIM Do not use.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
