Xerox VersaLink B7025 Service Manual

April 2017
2-560
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
124-321, 124-323
Launch Issue
Status Indicator RAPs
124-321 Backup SRAM Fail RAP
124-321 Write error occurred in the NVM on the ESS PWB.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
3. Ensure that the fax PWBs, PL 20.05 are installed correctly.
NOTE: Line 2 and 3 fax PWBs are options.
4. Reload the software, GP 4.
5. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
124-323 DC132 06 RAP
124-323 Internal control error was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Enter dC131. Compare NVM values 700-603, 700-604 and 700-605. All three values are dif-
ferent.
YN
Install a new drive PWB, PL 1.10 Item 3 or ESS PWB, PL 3.10 Item 6 as necessary.
Install a new drive PWB, PL 1.10 Item 3, then a ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
