Xerox VersaLink B7025 Service Manual

April 2017
2-40
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-136, 005-147
Launch Issue
Status Indicator RAPs
005-136 DADF Side 2 Registration Sensor On Jam RAP
BSD-ON: BSD 5.6 Document Scan, Invert and Exit Transportation
005-136 After the DADF pre registration sensor turned on at invert operation, the DADF regis-
tration sensor did not turn on within the specified time.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the exit roll, takeaway roll and registration roll for foreign substances
or wear. Clean or install new components as necessary, PL 5.50.
3. Enter dC330, code 005-110. Check the DADF registration sensor, PL 5.70 Item 3.
4. Enter dC330, code 005-206. Check the DADF pre registration sensor, PL 5.70 Item 3.
5. Enter dC330, code 005-008. Check the DADF feed motor, PL 5.30 Item 3.
6. Enter dC330, code 005-098. Check the DADF takeaway clutch, PL 5.35 Item 2.
7. Check the exit nip roll, PL 5.65 Item 17. Enter dC330, code 005-072. Check the exit nip
release solenoid, PL 5.35 Item 8.
8. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
9. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
005-147 DADF Pre Registration Sensor Off Jam During
Inverting RAP
BSD-ON: BSD 5.4 Document Feeding (1 of 2)
005-147 After the DADF feed motor started the reverse rotation at invert operation, the DADF
pre registration sensor did not turn off within the specified time.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
• GP 8 How to Check a Solenoid or Clutch.
Perform the steps that follow:
1. Check for a foreign substance in the document path.
2. Check the surface of the exit roll, takeaway roll, registration roll and out roll for foreign
substances or wear. Clean or install new components as necessary, PL 5.50.
3. Enter dC330, code 005-206. Check the DADF pre registration sensor, PL 5.70 Item 3.
4. Enter dC330, code 005-008. Check the DADF feed motor, PL 5.30 Item 3.
5. Check the exit nip roll, PL 5.65 Item 17. Enter dC330, code 005-072. Check the exit nip
release solenoid, PL 5.35 Item 8.
6. Check the drive gears, PL 5.35 for wear or damage. Install new components as neces-
sary.
7. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
