Xerox Versant 280 Press - REP 4.6 Carriage Belts


Xerox Customized Envelope Feeder – Problem Solving Guide 4-5
REP 4.6 Carriage Belts
Removal and Replacement
___1. PowerofftheFeederandunplugtheFeederpowercord.
___2. RemovetheRetardAssembly.
___3. RemovethefourTopCoverScrews.
___4. LoosenandremovetheDriveBeltfromtheMotor.

___5. RemovetheDischargeTensionRoller.

___6. RemovetheleftandrightscrewsfromtheDischarge
BearingHolder(CAUTION‐theassembly
willdrop).


