5-16
Disassembly and Reassembly
Service Manual
July 2003 WorkCentre PE16
Thermister Harness
Thermister
7. Unwrap the Thermister Harness, as shown below. 8. Remove the one screw securing the Thermister and
remove it, as shown below.
