1. turn on device, mic receiver, and mic launcher

2. plug mic receiver in device’s microphone port

3. then mic and device will be connected, get mouth close to sound collector of mic and speak.

4. adjust the volume of device or microphone

(PLS DO NOT PLACE THE DEVICE AND MICROPHONE TOO CLOSELY, IT MAY SCREAM)

FM radio:

1. pull out the antenna to receive a better signal

2. long press “pause/FM” button to turn mode to FM radio mode, LED screen shows FM frequency and “FM”

3. short press the “pause/FM” button to search FM station automatically, when there is a channel searched, the LED screen shows “CH 1”

“CH2″…

4. after searching, press “prev”/”next” to change FM stations you want to play

Music Player:

1. plug a flash drive/SD TF card in the USB/ SD TF card port

2. the device will play music automatically

3. press “pre”/”next” to choose previous/ next song

4. press “repeat”, LED screen shows “one” means repeat the song playing at present, “ALL” means repeat all of the songs

Speaker:

1. use the audio connect cable, plug one side in this audio input port, another side in another device’s

mic port

2. play music on the other device connected, this device will amplify it.

Product Parameter

Model NO.: N201 Speaker impedance: 4f2

Weight: 266g/0..58Ib/9.38oz The speaker size: 3 inch

Dim: 105*90*35mm/4.139.54*1.38inch Aux-in port: 3.5mm

Charger: DC 9V / 500mA Support MP3 music format, WAV, WMA

FM radio frequency: 87.5 MHZ–108 MHZ Battery: 7.4V/1800 mAh

Output power: 5-30w MAX SNR: 80dB
