ATX 連接線 24 Pin (20+4)
EPS/ATX12V 8 Pin(4+4) 連接線
PCIe 8 Pin(6+2) 連接線
PCIe 8 Pin(6+2) 連接線
SATA 連接線(4 SATA)
Peripheral 連接線(4-pin)
連接線 總長度
650mm (± 10mm)
650mm (± 10mm)
650mm (± 10mm)
650mm (± 10mm)
500mm (± 10mm)
500mm (± 10mm)
1
2
2
2
3
1
數量
CORE REACTOR 850 GOLD
直流連接線說明
電源規格表
電源風扇曲線
106105
* XPG Core Reactor Gold 系列電源
* 交流電源線 x 1
* 直流模組化電線組
* 直流模組化電線組儲存袋 x 1
* 束線袋x 10
* 手轉螺絲x 4
* 使用手冊
Fan Speed
型號
AC輸入範圍 DC出力
DC 輸出電壓
最高負載
混合型負載
尺寸 長 x 寬 x 高
總輸出
CoreReactor850Gold
+5VSB
3A
15W
-12V
0.3A
3.6W
+12V
70.8A
850W
850W
+3.3V
22A
+5V
22A
120W
100-240VAC, 47-63Hz, 12A
150 x 140 x 86mm
1800rpm
1600rpm
1400rpm
1200rpm
1000rpm
800rpm
600rpm
400rpm
200rpm
Load Condition
10% 30% 40% Typical 60% 70% 80% 90% FullLight
