XPRIT Beach Cruiser - Front Wheel Installation

5 / 16
Installing Your Front Wheel - Quick Release Version
Insert the front wheel in between the front fork on the bike. Be sure the fork is resting on
the outside of the axle.
1) Align the disc brake between the brake caliper as shown in Figure 2.
2) Insert the skewer into the wheel axle(See Figure 1). Note: spring, cam follower, and lever should
be on the LEFT side of disc brake. The adjustment nut and spring should be on the right side. (See
Figure 2)
3) Screw the skewer into the end nut until almost tight.
4) Lift the lever up until parallel with the front fork. You should feel the axle tighten into the front
forks. Your front wheel is now installed.
Figure 1
Figure 2
Bike Rear
Bike Front
Brake Caliper
and Disc Brake
on left side of
bike
—Front Fork
