ASSEMBLY MANUAL AND REPLACEMENT PARTS LIST
The Assembly Manual and Replacement Parts List is broken down into several sections. The rst section details the assembly of the
X-Terminator 2 RTR 4WD Nitro Buggy. Detailed drawings in a step-by-step format make it easy to disassemble and reassemble the Nitro
Buggy. This is useful when it’s necessary to replace damaged parts or when it’s time for a complete teardown for cleaning. The second
section lists all of the replacement parts that are available for purchase. For your convenience, a drawing of each replacement part is
shown, along with a description, manufacturer replacement number and the XTM Racing order number. For simplicity and ease of ordering
replacement parts, the XTM Racing order number is also listed on the corresponding parts drawings in the Assembly Manual, so it’s easy
for you to cross-reference the parts you need. A line listing of these parts is also included to make nding individual parts even easier. The
third section is a list of optional parts that are available, in the same format as the replacement parts.
When it comes time to order replacement parts and option parts, we recommend ordering directly from your local hobby retailer.
If your hobby retailer does not stock XTM Racing products, contact your closest distributor for a local stockist, using
the Customer Service Information below:
ASSEMBLY MANUAL (PAGES 25-51)
REPLACEMENT PARTS (PAGES 52-59)
OPTION PARTS (PAGES 60-64)
IMPORTANT INFORMATION ABOUT PART NUMBERS
There are two different part numbers shown in the Assembly Manual that can be used to cross-reference replacement parts to the
replacement parts list. The 6-digit numeric numbers (i.e.,149315, 149918, etc) are XTM Racing ordering numbers. When ordering
replacement parts, use these numbers. The other numbers (i.e., 2C, 2D, 1435, etc) are manufacturer assembly part numbers. These
numbers can’t be used for ordering parts, but they can be used to cross-reference parts to the 6-digit ordering number.
In the case of parts that are labeled 1A, 1B, 2A, 2B, 3A, 3B, etc, these are typically screws, nuts and bearings. If the particular parts are
part of a larger parts package (i.e., the grub screw 2C is included with the output cup 8), the part number listed for that particular part is
the part number for the larger package. If the parts are separate and are not part of a larger package, a separate part number is provided
that corresponds to a package of parts (i.e., a package of 10 cap screws or 10 lock nuts, etc).
