Xtool D1 Pro 40 W - Page 10

18
17
4. Replace the main control board
(1) Remove the original main control board
The largest processing area varies according to laser module. You need to set the
position of position limit piece A, accordingly.
(1) (3)(2)
For laser module 40 W For laser module 20 W For laser module 10 W & 5 W
