XtremeMac TANGO TRX - Page 9

1 2
3
4
5
3
7
6
2
9
1
3
4
10
5 6 7 8
AUX IN
18V 2.5A
2
1
9
Volume control knob1.
Dock connector2.
LED status indicators - source, volume, bass/treble3.
Play/pause control4.
Bass CONTROL5.
Treble control6.
Source control - iPod / iPhone, Bluetooth, Aux7.
Power button8.
iPod adapter insert holes9.
IR remote sensor10.
Line in jack1.
AC power jack2.
