While Yale® has included several features to prevent lockout
(9-Volt battery jumper, low battery warnings), it is still possible
for a lockout situation to occur. Because the YRL236 does not
have a key, Yale® recommends using YRL236 in an environment
where there are additional entry points into dwelling.
*NOTE TO INSTALLER AND CONSUMER
Using Your Lock
Keypad
Speaker
Low Battery Indicator
(flashes red)
Battery Back-up*
Hold a 9V battery to the
terminals in case of dead
lock batteries and no key
Press any key
to wake keypad
Press to enter
or unlock
Mechanical Key (YRL216)
Back-up entry method
All Code Lockout
(keypad flashes)
Enter Master Entry Code
and press to access
Settings Menu
or Key-Free Cylinder
(YRL236)
Inside Lock
Thumbturn
Inside Indicator Light
Speaker
