Yale CPA Series User Manual

19
Yale-Part. No. Yale-Part. No.
No. Description Qty.
CPA 20-8
CPA 30-6
CPA 40-4
CPA 50-3
CPA 60-3
No. Description Qty.
CPA 20-8
CPA 30-6
CPA 40-4
CPA 50-3
CPA 60-3
Planetary gearbox, ass. 1 00600230 27 Planet carrier assy. 1 00600251
1 Housing 1 00600237 27.1 Washer 1 00600252
2 Ring 1 00600238 27.2 Planet shaft 3 00600253
3 Planet carrier 1 00600239 28 Brake lining 2 00600254
4 Oil seal 1 09172110 29 Annulus 1 00600255
5 Bearing 1 09150043 30 Thrust washer 3 09153043
6 Thrust washer 6 09153043 31 Needle bearing 3 09153090
7 Planet gear 3 00600240 32 Planet gear 3 00600171
8 Needle bearing 6 09153090 33 Washer 1 00600256
9 Spacer ring 3 00600241 34 Retaining ring 2 09130034
10 Planet shaft 3 00600242 35 Shaft 1 00600257
11 Retaining ring 1 09129070 36 Bearing 1 09150043
13 Ring 1 00600243 37 Retaining ring 2 09129029
14 Retaining ring 1 09129071 38 Lock screw 1 00600258
15 Ring 1 00600244 39 Pin 1 00600259
16 O-Ring 1 09171352 40 O-Ring 1 09171169
17 Set screw 1 09114134 41 Cup spring 4 09120041
18 Oil seal 1 09172112 42 Adjuster 1 00600260
19 Shim 1 09121234 43 O-Ring 1 09171170
20 Bearing 1 09151101 44 Plug 1 09110052
21 Sun wheel 1 00600245 45 Gasket 1 09179004
22 Planet carrier assy. 1 00600246 46 Ball 1 09159011
22.1 Washer 1 00600247 47 Set screw 1 09114136
22.2 Planet shaft 3 00600248 48 Shim 1 09121056
23 Thrust washer 3 09153043 50 Coupling 1 00608879
24 Needle bearing 3 09153090 51 Cover 1 00600262
25 Planet gear 3 00600249 52 Screw 4 09102019
26 Sun wheel 1 00600250
Attention: When ordering spare parts please indicate item number and manufacturing year of the unit.
