Yale CPA Series User Manual

2
Weight with std. height 3m**Model Lifting
ca
p
acit
y
in kg/
chain fall
Lifting speed
with rated load*
m/min
Lifting speed
without load*
m/min
Lowering speed
with rated load *
m/min
Motor
rating
kW
Hook
design
kg
Push
trolley
kg
Geared
trolley
kg
Motor
trolley
kg
CPA 20-8 2000/1 6,4 8,6 9,5 2,6 121 184 188 199
CPA 30-6 3000/1 5,2 8,6 11,3 3,2 121 184 188 199
CPA 40-4 4000/2 3,2 4,4 4,8 2,6 140 202 206 218
CPA 50-3 5000/2 2,9 4,4 5,2 3,0 140 202 206 218
CPA 60-3 6000/2 2,6 4,4 5,6 3,2 140 202 206 218
*Value at 6 bar (flow pressure) Air consumption with rated load 4,7 m
3
/min **Other lifting heights available
Motor trolley
Lifting capacity
kg
Flange
width
mm
Size Curve
radius
min.
m
Travel
speed
m/min
Motor ratin
g
kW
2000 - 6000 98 – 180 A 1,8 18 0,55
2000 - 6000 180 - 300 B 1,8 18 0,55
Fig. 1
Trolley
Pendant control
Trolley motor
Air filter
Chain hoist
Buffer
Chain stop
Load chain 11 x 31
Buffer
Lower block
Safety latch
Load hook
Technical Data CPA
Technical Data Motor Trolley
Controls
Air pressure hose

Yale CPA Series Specifications
