Table 4. Auxiliary Control Levers
Function
Direction of Movement
Load or Equipment Control Lever
1. REACH Retract/Extend Backward/Forward
2. SIDESHIFT Right/Left Backward/Forward
3. PUSH-PULL Backward/Forward Backward/Forward
4. ROTATE Clockwise/Counterclockwise Backward/Forward
5. UPENDER Up/Down Backward/Forward
6. SCOOP Up/Down Backward/Forward
7. LOAD STABILIZER Down (Clamp)/Up (Release) Backward/Forward
8. SWING (FORKS) Right/Left Backward/Forward
9. FORK SPREAD Together/Apart Backward/Forward
10. CLAMP Clamp/Release Backward/Forward
