Yale Veracitor GLC060VX

To Next Page

To Previous Page

1. CHECK FOR DAMAGE (REMOVE NAILS, GLASS AND OTHER OBJECTS FROM THE TREAD)

2. MAKE SMOOTH EDGES

3. CHECK THE TIRE PRESSURE (PNEUMATIC TIRES)

Figure 21. Check the Tires

Maintenance

136
