Table 3. Operator Controls (See Figure 9) (Continued)
Item
No.
Item Function
15 Accelerator Pedal This pedal controls the speed of the engine and is operated by the operator's right
foot. It is used on units that have a Direction Control Lever.
16 Direction
Control
Switch
The Direction Control Switch for the transmission is next to the auxiliary horn button
on the armrest. The Direction Control Switch is used on lift trucks without a Foot
Directional Control pedal.
17 Auxiliary
Horn
Button
Auxiliary horn button functions when the key or keyless ignition is in the ON position
and up to 20 minutes after the key or keyless ignition is turned to the OFF position.
Model Description
56
