Yamaha 70B - Page 99

6-6
E
LOWR
DISASSEMBLY
10) Oil seals and needle bearing
Å For USA and Canada
ı Except for USA and Canada
Slide hammer set:
YB-6096.................................. 1
Stopper guide plate:
90890-06501........................... 2
Bearing puller:
90890-06535........................... 3
Stopper guide stand:
90890-06538........................... 4
Driver rod:
YB-6071/90890-06602 ........... 5
Needle bearing attachment:
YB-6153/90890-06612 ........... 6
Å
ı
11) Pinion nut, pinion and drive shaft
bearing inner race
Å For USA and Canada
ı Except for USA and Canada
NOTE:
For ease of reassembly and adjustment,
keep shim packs in their groups as
removed.
Drive shaft holder:
50, 60, 70 hp:
YB-6049/90890-06518 ........ 1
75, 80, 90 hp:
YB-6151/90890-06519 ........ 2
Pinion nut holder:
90890-06505........................... 3
Å
1
ı
2
3
