Yamaha CL Series User Manual

Reading and Writing CSV files
V4.1 Supplementary Manual
25
Port name notation for input patches and output patches
Original notation
(Normal format)
Original notation
(Short format)
Additional notation when reading a CSV file
* Underlined words can be omitted.
* [n] indicates a number (such as a channel number).
NONE NONE None
DANTE [n] DNT [n] Dante [n]
OMNI [n] OMNI [n]
Omni [n]
AD [n]
INPUT [n] INPUT [n] Input [n]
PB L PBL Playback Output
Left
PB R PBR Playback Output
Right
SLOT1 [n] SL1 [n] Slot1 [n]
SLOT2 [n] SL2 [n] Slot2 [n]
SLOT3 [n] SL3 [n] Slot3 [n]
FX [n] A FX[n]A Effect Rack
[n] A
FX [n] B FX[n]B Effect Rack
[n] B
PRFX [n] A PR[n]A Premium Rack
[n] A
PRFX [n] B PR[n]B Premium Rack
[n] B
GEQ [n] A GEQ[n]A GEQ Rack
[n] A
GEQ [n] B GEQ[n]B GEQ Rack
[n] B
MIX [n] MX [n] Mix Channel
[n]
MATRIX [n] MT [n] Matrix Channel
[n]
STEREO L STL
Stereo Output
Left
Main L
STEREO R STR
Stereo Output
Right
Main R
MONO (C) MONO Mono (C)
STEREO L+C STLC Stereo Output
L+C
STEREO R+C STRC Stereo Output
R+C
MONITOR L MON L Monitor Left
MONITOR R MON R Monitor Right
MONITOR C MON C Monitor Center
CUE L CUE L
Cue A
Cue Left
CUE R CUE R Cue Right
CUE B L CUE BL Cue B Left
CUE B R CUE BR Cue B Right
INS CH [n] IC [n] Insert1
Input Channel [n]
INS MIX [n] IM [n] Insert1
Mix Channel [n]
INS MATRIX [n] IMT [n] Insert1
Matrix Channel [n]
INS STEREO L ISTL Insert1
Stereo Output Left
INS STEREO R ISTR Insert1
Stereo Output Right
INS MONO (C) IMONO Insert1
Mono (C)
DIR CH [n] DI [n] Direct Input
Channel
CAS MIX [n] CMX [n] Cascade Mix [n]
CAS MARIX [n] CMT [n] Cascade Matrix [n]
CAS STEREO L CSTL Cascade Stereo Left
CAS STEREO R CSTR Cascade Stereo Right
CAS MONO (C) CMONO Cascade Mono (C)
CAS CUE L CCUE L Cascade Cue Left
CAS CUE R CCUE R Cascade Cue Right
CAS CUE B L CCUE BL Cascade Cue B Left
CAS CUE B R CCUE BR Cascade Cue B Right
Original notation
(Normal format)
Original notation
(Short format)
Additional notation when reading a CSV file
* Underlined words can be omitted.
* [n] indicates a number (such as a channel number).

Yamaha CL Series Specifications

General

Dante Network	Yes
Touch Screen	Yes
Type	Digital Mixing Console
Control Surface	Yes
Mixing Channels	CL5: 72, CL3: 64, CL1: 48
Local I/O	CL5: 8 in / 8 out, CL3: 8 in / 8 out, CL1: 8 in / 8 out
USB Recording	Yes
EQ	4-band parametric EQ per channel
Effects	Yes
DAW Control	Yes
Word Clock	Yes
Input Channels	CL5: 72, CL3: 64, CL1: 48
Output Channels	CL5: 34, CL3: 34, CL1: 34
Sampling Rate	44.1kHz, 48kHz, 88.2kHz, 96kHz
Connectivity	Dante, USB
Recallable Scenes	Yes
Expandability	Yes
