Yamaha CL Series User Manual

Support for devices that do not feature Dante output
V4.1 Supplementary Manual
27
When the receiver is off
 QLXD4 and ULXD4 display
Overview window (INPUT CH window)
The HA display appears as shown below.
 AXT400 display
When the receiver is on and connected via a ShowLink® remote control
When the receiver is on and not connected via a ShowLink® remote control
 QLXD4 and ULXD4 display
The RF channel (A or B) display
has the same design as for the
AXT400.
The RF level is shown for two
channels (A and B).
The RF channel (A or B) display
has the same design as for the
AXT400.

Yamaha CL Series Specifications

General

Dante Network	Yes
Touch Screen	Yes
Type	Digital Mixing Console
Control Surface	Yes
Mixing Channels	CL5: 72, CL3: 64, CL1: 48
Local I/O	CL5: 8 in / 8 out, CL3: 8 in / 8 out, CL1: 8 in / 8 out
USB Recording	Yes
EQ	4-band parametric EQ per channel
Effects	Yes
DAW Control	Yes
Word Clock	Yes
Input Channels	CL5: 72, CL3: 64, CL1: 48
Output Channels	CL5: 34, CL3: 34, CL1: 34
Sampling Rate	44.1kHz, 48kHz, 88.2kHz, 96kHz
Connectivity	Dante, USB
Recallable Scenes	Yes
Expandability	Yes
