Yamaha DM2000 Service Manual

DM2000
22
SmartMedia CARD Slot
CARD
3.3V
MATRIX SELECT
MATRIX SELECT
DISPLAY
MATRIX 2 MATRIX 4 MATRIX 3
MATRIX 1
q
w
q MATRIX SELECT [DISPLAY] button
w [MATRIX 1]–[MATRIX 4] buttons
AUX SELECT
q AUX SELECT [DISPLAY] button
w [AUX 1]–[AUX 12] buttons
AUX 2 AUX 1 AUX 3 AUX 4
AUX 6 AUX 5 AUX 7
AUX 10 AUX 9 AUX 11
AUX 8
AUX 12
AUX SELECT
DISPLAY
q
w
AUX / MTRX PAN
ASSIGN 4 ASSIGN 3
DISPLAY
ASSIGN 2 ASSIGN 1
PAN SEND LEVEL
INSERTSEND ASSIGNOUTPUTINPUT
q
r
w e
ENCODER MODE
AUX/ MTRXFADER
FADER MODE
q w
ENCODER MODE
q ENCODER MODE [DISPLAY] button
w [PAN] button
e [AUX/MTRX] button
r [ASSIGN 1]–[ASSIGN 4] buttons
FADER MODE
q [FADER] button
w [AUX/MTRX] button

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
