Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
84
P.C.B. MAIN
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
R110 V3946100 R.MTL.OXD 2.7KΩ0.5W
R111 V3945100 R.MTL.OXD 390Ω0.5W
R112 V3945600 R.MTL.OXD 1KΩ0.5W
R113 V3945500 R.MTL.OXD 820Ω0.5W
R115 VP941600 R.MTL.OXD 5.6KΩ1W
R116 VP941600 R.MTL.OXD 5.6KΩ1W
R117 V3946100 R.MTL.OXD 2.7KΩ0.5W
R118 V3945100 R.MTL.OXD 390Ω0.5W
R119 V3945600 R.MTL.OXD 1KΩ0.5W
R120 V3945500 R.MTL.OXD 820Ω0.5W
R122 VP941600 R.MTL.OXD 5.6KΩ1W
R123 VP941600 R.MTL.OXD 5.6KΩ1W
R124 V3946100 R.MTL.OXD 2.7KΩ0.5W
R125 V3945100 R.MTL.OXD 390Ω0.5W
R126 V3945600 R.MTL.OXD 1KΩ0.5W
R127 V3945500 R.MTL.OXD 820Ω0.5W
R129 VP941600 R.MTL.OXD 5.6KΩ1W
R130 VP941600 R.MTL.OXD 5.6KΩ1W
R131 V3946100 R.MTL.OXD 2.7KΩ0.5W
R132 V3945100 R.MTL.OXD 390Ω0.5W
R133 V3945600 R.MTL.OXD 1KΩ0.5W
R134 V3945500 R.MTL.OXD 820Ω0.5W
R136 VP941600 R.MTL.OXD 5.6KΩ1W
R137 VP941600 R.MTL.OXD 5.6KΩ1W
R138 HV755100 R.CAR.FP 100Ω1/4W
Z R139 HV754100 R.CAR.FP 10Ω1/4W
Z R143 VP939700 R.MTL.FLM 4.7Ω1W
Z R144 V3944800 R.MTL.OXD 220Ω0.5W
Z R145 V3873200 R.WW 0.22Ω3W
Z R146 VP939700 R.MTL.FLM 4.7Ω1W
R147 HV755100 R.CAR.FP 100Ω1/4W
Z R148 VP939700 R.MTL.FLM 4.7Ω1W
Z R149 V3944800 R.MTL.OXD 220Ω0.5W
Z R150 V3873200 R.WW 0.22Ω3W
Z R151 VP939700 R.MTL.FLM 4.7Ω1W
R152 HV755100 R.CAR.FP 100Ω1/4W
Z R153 HV754100 R.CAR.FP 10Ω1/4W
Z R154 V3944800 R.MTL.OXD 220Ω0.5W
Z R155 VU981700 R.MTL.PLAT 0.22Ω+0.223W
Z R156 HV754100 R.CAR.FP 10Ω1/4W
R157 HV755100 R.CAR.FP 100Ω1/4W
Z R158 HV754100 R.CAR.FP 10Ω1/4W
Z R159 V3944800 R.MTL.OXD 220Ω0.5W
Z R160 VU981700 R.MTL.PLAT 0.22Ω+0.223W
Z R161 HV754100 R.CAR.FP 10Ω1/4W
R162 HV755100 R.CAR.FP 100Ω1/4W
Z R163 VP939800 R.MTL.OXD 10Ω1W
Z R164 V3944800 R.MTL.OXD 220Ω0.5W
Z R165 V3873200 R.WW 0.22Ω3W
Z R166 VP939800 R.MTL.OXD 10Ω1W
Z R168 HV756150 R.CAR.FP 1.5KΩ1/4W
Z R173 VP939800 R.MTL.OXD 10Ω1W
Z R178 VP939800 R.MTL.OXD 10Ω1W
Z R183 VP939800 R.MTL.OXD 10Ω1W
R188 VP939800 R.MTL.OXD 10Ω1W
R193 VP939800 R.MTL.OXD 10Ω1W
Z R203 VP939700 R.MTL.FLM 4.7Ω1W
Z R204 VP939700 R.MTL.FLM 4.7Ω1W
Z R205 VP940800 R.MTL.OXD 470Ω1W
Z R206 VP939700 R.MTL.FLM 4.7Ω1W
Z R207 VP940800 R.MTL.OXD 470Ω1W
Z R208 HV755100 R.CAR.FP 100Ω1/4W
Z R209 HV756100 R.CAR.FP 1KΩ1/4W
Z R211 VP940800 R.MTL.OXD 470Ω1W
Z R212 VP940800 R.MTL.OXD 470Ω1W
R222 HV753470 R.CAR.FP 4.7Ω1/4W
R226 HV754100 R.CAR.FP 10Ω1/4W
R227 HV754100 R.CAR.FP 10Ω1/4W
R228 HV754100 R.CAR.FP 10Ω1/4W
R229 HV754100 R.CAR.FP 10Ω1/4W
R230 HV754100 R.CAR.FP 10Ω1/4W
R235 VP940900 R.MTL.OXD 560Ω1W
R236 VP940900 R.MTL.OXD 560Ω1W
Z R270 HV754100 R.CAR.FP 10Ω1/4W
Z R271 HV756470 R.CAR.FP 4.7KΩ1/4W
R275 HV755100 R.CAR.FP 100Ω1/4W
R282 HV755100 R.CAR.FP 100Ω1/4W
R289 HV755100 R.CAR.FP 100Ω1/4W
R296 HV755100 R.CAR.FP 100Ω1/4W
R303 HV755100 R.CAR.FP 100Ω1/4W
R331 HV753220 R.CAR.FP 2.2Ω1/4W
R332 HV753220 R.CAR.FP 2.2Ω1/4W
R333 HV753220 R.CAR.FP 2.2Ω1/4W
R334 HV753220 R.CAR.FP 2.2Ω1/4W
R335 HV753220 R.CAR.FP 2.2Ω1/4W
R336 HV753220 R.CAR.FP 2.2Ω1/4W
Z R374 HV753100 R.CAR.FP 1Ω1/4W
Z R375 HV753100 R.CAR.FP 1Ω1/4W
Z RY101 VU566700 RELAY DG24D2‑OS/M
Z RY102 VK438300 RELAY DH24D2‑OT/M2
Z RY103 VK438300 RELAY DH24D2‑OT/M2
Z RY104 VU566700 RELAY DG24D2‑OS/M
ST251 V4040500 SCR.TERM M3
ST371 V4040500 SCR.TERM M3
ST372 V4040500 SCR.TERM M3
ST373 V4040500 SCR.TERM M3
SW351 VV523900 SW.PUSH PBS‑YM‑001
Z SW371 V4104200 SW.SLIDE SL13B‑022‑AMCS
TE101 V5912000 TERM.SP 6PLTS0610 BG
* TE101 V6771100 TERM.SP 6PLTS0610‑1009 RT
TE331 V5912200 TERM.SP 8PLTS0810 BG
* TE331 V6771200 TERM.SP 8PLTS0810‑1011 RT
BB070700 GND.MTL
