Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
85
P.C.B. POWER
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
* V7210200 P.C.B. POWER RT
* V7210400 P.C.B. POWER B
* V7210500 P.C.B. POWER G
CB701 VQ962800 CN.BS.PIN 7P
CB702 Vi878500 CN.BS.PIN 7P
CB721 Vi878500 CN.BS.PIN 7P
CB741 VQ960900 CN.BS.PIN 6P
CB742 VP206500 HOLDER.FUS EYF‑52BCT G
CB743 VP206500 HOLDER.FUS EYF‑52BCT G
CB744 VP206500 HOLDER.FUS EYF‑52BCT
CB745 VP206500 HOLDER.FUS EYF‑52BCT
CB746 VG879900 CN.BS.PIN 2P
CB761 VP206500 HOLDER.FUS EYF‑52BCT RT
CB762 VP206500 HOLDER.FUS EYF‑52BCT RT
C703 VG287600 C.EL 100uF25V
C704 VG287600 C.EL 100uF25V
C705 VG288500 C.EL 10uF50V
C706 UR838100 C.EL 100uF16V
C707 VG288500 C.EL 10uF50V
C708 UR838100 C.EL 100uF16V
C711 UR847100 C.EL 10uF25V
C712 UR847100 C.EL 10uF25V
C713 UR838100 C.EL 100uF16V
C714 UR847100 C.EL 10uF25V
Z C723 UR749470 C.EL 4700uF25V
Z C724 UR749470 C.EL 4700uF25V
Z C725 UR73A100 C.EL 10000uF16V
C727 VE326000 C.MYLAR.ML 0.1uF50V
C728 VE326000 C.MYLAR.ML 0.1uF50V
C729 VE326000 C.MYLAR.ML 0.1uF50V
C730 VE326000 C.MYLAR.ML 0.1uF50V
C731 VS745400 C.POL.MTL 0.1uF100V
Z C732 UR73A100 C.EL 10000uF16V
C743 VJ599100 C.CE.TUBLR 0.1uF50V
C744 UR749100 C.EL 1000uF25V
C745 UA654100 C.MYLAR 0.01uF50V BG
C746 UR897100 C.EL 10uF100V RT
C747 UA654100 C.MYLAR 0.01uF50V
Z C748 V6185300 C.CE.SAFTY 0.01uF275V
C749 UU167100 C.EL 10uF50V RT
C750 UA654100 C.MYLAR 0.01uF50V RT
C751 UA654100 C.MYLAR 0.01uF50V RT
C752 UU147100 C.EL 10uF25V RT
Z D722 VQ379300 DIODE.BRG S1VB201.0A200V
Z D723 V4269600 DIODE.BRG D2SBA201.5A200V
D741 VD631600 DIODE 1SS133,176
D742 VG440400 DIODE.ZENR MTZJ13A13V RT
D743 VV307700 DIODE 1N4002S
D744 VV307700 DIODE 1N4002S
D745 VV307700 DIODE 1N4002S
D746 VV307700 DIODE 1N4002S
D747 VV307700 DIODE 1N4002S RT
D748 VD631600 DIODE 1SS133,176 RT
Z F741 VT942900 FUSE TH2.5A250V
Z F741 VT942900 FUSE TH2.5A250V G
Z F742 KB000790 FUSE T4.0A250V BG
Z F742 VS823300 FUSE T8.0A125V RT
Z F761 KB000790 FUSE T4.0A250V RT
HS741 VR506800 HEAT.SINK PUH16‑25
Z IC701 XJ608A00 IC NJM7812FA
Z IC702 XD343A00 IC NJM79M12FA
Z IC703 XJ607A00 IC NJM7805FA5V
Z IC704 XE436A00 IC NJM79M05FA
Z IC705 XJ607A00 IC NJM7805FA5V
Q741 iC174020 TR 2SC1740SR,S
Q742 VR510800 TR 2SD2396J,K RT
Q743 VR510800 TR 2SD2396J,K RT
Q744 iE102620 FET 2SK246Y RT
R705 HV753100 R.CAR.FP 1Ω1/4W
R706 HV753100 R.CAR.FP 1Ω1/4W
R709 HV753100 R.CAR.FP 1Ω1/4W
R710 VP939500 R.MTL.FLM 1Ω1W
R711 VP939600 R.MTL.FLM 2.2Ω1W
Z RY741 V2712300 RELAY DCSDT‑S‑112LMR
ST741 V4040500 SCR.TERM M3
Z * SW761 V7182300 VOLT.SELCT R8140213 RT
Z T741 XW608A00 TRANS.PWR BG
Z T741 XW974A00 TRANS.PWR RT
Z TE741 V5867400 OUTLET.AC 2PAC‑182‑GB‑11V RT
Z TE741 VU543300 OUTLET.AC 1P B
Z TE741 VU543400 OUTLET.AC 2P G
EP600140 SCR.BND.HD 3x10MFZN2‑BL RT
