6-17
DRIVE SHAF
T
AND FORW
ARD GEAR
INST
ALL
ING THE BALL BEARING
Insta
ll:
Gear adjusti
ng shim(s)
Ball bearin
g
A
For USA and Canada
B
Except for USA and Canada
NOTE:
Install the bal
l bearing with
its
manufacturer’
s mark
facing towar
ds the
forward g
ear
.
Driver rod:
YB-06071/90890-06604
Attachmen
t:
YB-06167/90890-06634
143
145
