Extensions for Steinberg DAW for MOTIF XS6/7/8
Owner’s Manual
4
■
Project templates with Input/
Output Bus settings
With Extensions for Steinberg DAW installed, convenient
Project templates for the MOTIF XS will be installed to Cubase.
Each of these templates includes the appropriate settings for the
Input/Output buses of the VST Connection, meaning that you
can start multi-channel recording or AD input recording
smoothly by selecting one of the templates to create a new
Project, without having to set Audio Ports and Buses manually.
NOTE
• Set the AD Output of the MOTIF XS to “m13&14” by using the
MOTIF XS Editor or MOTIF XS instrument so that the setup of the
Project Template is equivalent to the setup of the MOTIF XS.
• Selecting a different Project Template will overwrite the current set-
tings of the Input/Output buses.
The following two Templates are installed:
• Yamaha MOTIF XS multi channel recording
When this template is selected, audio outputs from respective
channels of the MOTIF XS will be input to the respective
audio tracks of Cubase simultaneously.
The correspondences between the Input/Output Buses and
Device Port on the VST connection window are as follows:
• Yamaha MOTIF XS AD Input recording
When this template is selected, audio signals from the A/D
Input channel of the MOTIF XS will be input to an audio track
of Cubase. This template is convenient when using the
MOTIF XS as an external instrument of Cubase. The corre-
spondences between the Input/Output Buses and Device Port
on the VST connection window are same as the above table
with the exception that only “MOTIF XS AD in” is available
as the Input Bus.
Project templates for MOTIF XS6/7/8
Cubase Outputs
Output Bus Device Port
MOTIF XS Main
MOTIF XS Main L
MOTIF XS Main R
MOTIF XS Asgn
MOTIF XS Asgn L
MOTIF XS Asgn R
MOTIF XS mLAN
MOTIF XS mLAN L
MOTIF XS mLAN R
