8-9
8
2. Slide the handhold to the desired position
and align the holes in the handhold bar
with the holes in the handhold supports.
3. Insert the pins into the holes and secure
them with the wire loops. Make sure that
the handhold is properly secured before
starting off.
Seat and shoulder bolsters
The seats and shoulder bolsters are designed
to help keep you in the vehicle. Do not put
your hand or arm on or outside of the shoul-
der bolster during operation. Your hand or
arm may be struck by objects or crushed
against outside objects or the ground during
a rollover.
1. Handhold bar
2. Handhold support
1. Wire loop
