Yard-Man 454 - Page 17

17
Model 454
REF.
NO. PART NO. DESCRIPTION
1.
747-1152 Shift Rod
2.
649-0041 Upper Handle Ass’y
3.
649-0034 Lower Handle Ass’y
4.
710-3005 Hex Screw 3/8-16 x 1.25
5.
710-3056 Hex Screw 5/16-18 x 3.25
6.
711-0415 Clevis Pin 3/8-1.62
7.
712-0379 Flange Lock Nut 3/8-24
8.
712-0429 Hex Lock Nut 5/16-18
9.
714-0147 Cotter Pin
10.
720-0313 Grip
11.
720-0210A T-Knob
12.
720-0278A Foam Grip
14.
726-0317 Cable Tie
15.
735-0246 Plug
16.
736-0117 Flat Washer 3/8 x .620 x .033
17.
736-0242 Bell Wash. .340 I.D. x .872 O.D.
18.
738-0958 Shoulder Spacer
19.
784-0190 Handle Adjustment Crank
20.
784-0191 Hex Nut Ret. Bracket
21.
786-0120 Depth Stake
22.
747-1219 Bail Clutch
23.
786-0181 Shift Lever Rod
24.
686-0044A Tine Shield Cover Ass’y
25.
710-0176 Hex Cap Screw 5/16-18 x 2.75
26.
710-3008 Hex Cap Screw 5/16-18 x .750
27.
710-3097 Carriage Bolt 3/8-16 x 1.0
28.
712-0421 Wing Nut
29.
736-0169 Lock Washer 3/8
30.
712-3004A Flange Nut 5/16-18
31.
726-0106 Cap Nut
32.
738-0849 Hex Screw 5/16-18 x .75" Lg.
33.
747-0432 Rod
34.
750-0885 Spacer .435 O.D. x .322 I.D.
35.
786-0090 Shoulder
36.
786-0113 Tine Shield Hinge Flap
37.
786-0176 R.H. Handle Brkt.
38.
786-0177 L.H. Handle Brkt.
39.
786-0178 Tine Shield
40.
786-0179 Tine Shield Brkt.
41.
786-0180 Shoulder Spacer Brkt.
42.
686-0109 Shift Crank Ass’y
44.
710-1017 Screw 1/4-14 x .625
46.
715-0120 Spirol Pin 3/16 x 1.00
49.
784-0208C Shift Cover
50.
711-0415 Clevis Pin
51.
712-3054 Hex Nut 3/8-24 Thd.
53.
742-0305 13" Dia. Articulating Tine
54.
738-0689 Shld. Bolt 1/2" DIa. x .175
55.
736-0208 Fl-Wash. .51" I.D. x 1.50"
56.
736-0253 Bell-Wash. .515" I.D. x 1.14"
57.
738-0688 Shld. Bolt 1/2" Dia x .320
58.
784-0160 Tine Adapter Ass’y 18"
59.
714-0149B Internal Cotter Pin
60.
735-0127 Rubber Washer
61.
714-0104 Cotter Pin
62.
710-3022 Hex Screw 3/8-16 x 2.75" Lg.
63.
736-0204 Flat Washer
64.
712-0431 Flange Nut .344 I.D. x .62 O.D.
65.
736-0169 Lock Washer
66.
712-0798 Hex Nut 3/8-16
67.
710-0946 Truss Screw 1/4-20 x .65
68.
712-0324 Hex Lock Nut 1/4-20 Gr. 8
69.
726-0273 Battery Hose Clamp 5/16
70.
736-3090 Flat Washer .260 x .720 x .060
REF.
NO. PART NO. DESCRIPTION
Labels
Ref.
No.
Part No. Code Description
N/I 777S30037 Model Plate
N/I 777I20283 Shift Plate Facing Operator
N/I 777D02311 Engine Spinner
N/I 777D01294 YM, Side of Belt Guard
N/I 777I20358 Place Hand Here on Handle
N/I 777I20457 Gear Selection on Handle
N/I 777D01159 Front Counterweight
