Yard-Man RT65 - Page 15

15
MODEL 458
REF.
NO. PART NO. DESCRIPTION
1 611-0020 Wheel Shaft Ass’y: 33T
2 611-0021 Tine Shaft Ass’y: 18T
3 611-0128 Jack Shaft Ass’y
4 611-0129 Input Shaft Ass’y
5 617-0058 Rev. Idler Gear Ass’y: 30T
6 617-0059 Ftine Idler Gear Ass’y: 30T
7 617-0060 Tine Input Sprocket Ass’y: 9T
8 617-0061 Wheel Input Sprocket Ass’y: 10T
9 617-0062 Gear Ass’y: 11T
10 686-0108 R.H. Housing Ass’y
11 710-0376 Hex Bolt 5/16-18 x 1" Lg.
12 710-0599 Hex S-Tap Scr. 1/4- 20 x .5"
13 710-0604 Hex S-Tap Scr. 5/16-18 x .625"
14 710-3008 Hex Bolt 5/16-18 x .75"
15 711-1349 Input Shaft
16 712-0378 Hex Nut 7/16-20
17 712-3004A Flange Nut 5/16-18
18 713-0367 #420 Chain 1/2 Pitch x 50 Links
19 713-0484 #50 Chain 5/8 Pitch x 54 Links
20 716-0865 Snap Ring
21 717-0853 Shifting Fork
22 717-1582 Spur Gear 44T
23 717-1583 Spur Gear 30T
24 717-1584 Spur Gear 30T
25 717-1585 Spur Gear 44T
26 717-1587 Spur Gear 44T
27 717-1594 Spur Gear 16T
28 721-0378 Seal 1.0 Shaft
29 721-0379 Seal .75 Shaft
31 726-0277 Taper Cap Ring
32 732-0496 Compression Spring .50" Lg.
33 736-0163 Thrust Wash. 1.03" I.D. x 1.62" O.D.
34 736-0351 Fl-Wash .76" I.D. x 1.5" O.D.
35 736-0407 Bell-Wash .45" I.D. x 1.0"
36 736-0518 Thrust Wash. .445 x 1.92 x .060
37 736-3088 Fl-Wash. .635" I.D. x 1.59 O.D.
40 738-0645 Detent Shaft 1/2" Dia.
41 738-0648 Jack Shaft .625 x 2.385
42 738-1013 Jack Shaft .625 x 5.0
43 741-0124 Ball Bearing
44 741-0420 Flange Bearing 1.0 x 2.5 x 1.38
45 741-0421 Flange Bearing .75 x 2.5 x 1.38
46 741-0563 Ball Bearing . 6692 x 5745 x .466
47 741-0862 Detent Ball .250
48 750-0258 Spacer .315
49 750-0570 Spacer 1.0 I.D x 2.0 O.D. x .440
50 750-0664 Spacer .505 I.D. x .88 O.D. x .440
51 750-0671 Spacer .75 x 2.0 x .50
52 786-0171 L.H. Chain Case Ass’y
53 786-0238 Gear Positioner Bracket
- 737-0300 Benelene 920 Grease
- 737-0288 Never Seez Grease
- 686-0107 Gear Case Assembly Complete
REF.
NO. PART NO. DESCRIPTION
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Yard-Man
Green, the part number to order would be
700-xxxx-0665.
Yard-Man Green: 0665
Yard-Man Yellow: 0674
Powder Black: 0637
