Yard-Man RT65 - Page 17

17
MODEL 458
REF.
NO. PART NO. DESCRIPTION
1 747-1152 Shift Rod
2 649-0041 Upper Handle Ass’y
3 649-0034 Lower Handle Ass’y
4 710-3005 Hex Screw 3/8-16 x 1.25
5 710-3056 Hex Screw 5/16-18 x 3.25
6 711-0415 Clevis Pin 3/8-1.62
7 712-0379 Flange Lock Nut 3/8-24
8 712-0429 Hex Lock Nut 5/16-18
9 714-0147 Cotter Pin
10 720-0313 Grip
11 720-0210A T-Knob
12 720-0278A Foam Grip
14 726-0317 Cable Tie
15 735-0246 Plug
16 736-0117 Flat Washer 3/8 x .620 x .033
17 736-0242 Bell Wash. .340 I.D. x .872 O.D.
18 738-0958 Shoulder Spacer
19 784-0190 Handle Adjustment Crank
20 784-0191 Hex Nut Ret. Bracket
21 786-0120 Depth Stake
22 747-1219 Bail Clutch
23 786-0181 Shift Lever Rod
24 686-0044A Tine Shield Cover Ass’y
25 710-0176 Hex Cap Screw 5/16-18 x 2.75
26 710-3008 Hex Cap Screw 5/16-18 x .750
27 710-3097 Carriage Bolt 3/8-16 x 1.0
28 712-0421 Wing Nut
29 736-0169 Lock Washer 3/8
30 712-3004A Flange Nut 5/16-18
31 726-0106 Cap Nut
32 738-0849 Hex Screw 5/16-18 x .75" Lg.
33 747-0432 Rod
34 750-0885 Spacer .435 O.D. x .322 I.D.
35 786-0090 Shoulder
36 786-0113 Tine Shield Hinge Flap
37 786-0176 R.H. Handle Brkt.
38 786-0177 L.H. Handle Brkt.
39 786-0178 Tine Shield
40 786-0179 Tine Shield Brkt.
41 786-0180 Shoulder Spacer Brkt.
42 686-0109 Shift Crank Ass’y
44 710-1017 Screw 1/4-14 x .625
46 715-0120 Spirol Pin 3/16 x 1.00
49 784-0208C Shift Cover
50 711-0415 Clevis Pin
51 712-3054 Hex Nut 3/8-24 Thd.
53 742-0305 13" Dia. Articulating Tine
54 738-0689 Shld. Bolt 1/2" DIa. x .175
55 736-0208 Fl-Wash. .51" I.D. x 1.50"
56 736-0253 Bell-Wash. .515" I.D. x 1.14"
57 738-0688 Shld. Bolt 1/2" Dia x .320
58 784-0160 Tine Adapter Ass’y 18"
59 714-0149B Internal Cotter Pin
60 735-0127 Rubber Washer
61 714-0104 Cotter Pin
62 710-3022 Hex Screw 3/8-16 x 2.75" Lg.
63 736-0204 Flat Washer
64 712-0431 Flange Nut .344 I.D. x .62 O.D.
65 736-0169 Lock Washer
66 712-0798 Hex Nut 3/8-16
67 710-0946 Truss Screw 1/4-20 x .65
68 712-0324 Hex Lock Nut 1/4-20 Gr. 8
69 726-0273 Battery Hose Clamp 5/16
70 736-3090 Flat Washer .260 x .720 x .060
REF.
NO. PART NO. DESCRIPTION
Labels
Ref.
No.
Part No. Code Description
N/I 777S30037 Model Plate
N/I 777I20283 Shift Plate Facing Operator
N/I 777D02311 Engine Spinner
N/I 777D01294 YM, Side of Belt Guard
N/I 777I20358 Place Hand Here on Handle
N/I 777I20457 Gear Selection on Handle
N/I 777D01159 Front Counterweight
