19
MODEL 458
REF.
NO. PART NO. DESCRIPTION
1 686-0111 Belt Cover Brkt. Ass’y
2 710-0237 Hex Bolt 5/16-24 x .62" Lg.
3 710-0412 Hex Bolt 1/4-28 x .75" Lg.
4 710-0502A Hex Wash.TT-Sems Screw 3/8-16 x
1.250" Lg.
5 710-0591 Hex Bolt 3/8-24 x 1.00
6 710-0599 Hex Wash. Hd. S-Tap Scr.
7 710-0723 Hex Cap Screw 3/8-16 x 1.25
8 712-0266 Ctr. Lock Jam Nut 3/8-16
9 712-0267 Hex Nut 5/16-18
10 714-0104 Internal Cotter Pin
11 736-0104 Hairpin Clip
12 736-0119 L-Wash. 5/16" I.D.
13 736-0176 Fl-Wash. 1/4 I.D. x .93 O.D.
14 736-0271 Spring-Wash. .317 x .625 O.D. x .099
15 736-0329 L-Wash. 1/4" I.D.
16 736-0452 Bell-Wash. .396 x 1.140 x .095
17 738-0876 Shld. Nut 7/16-20
18 746-1117 Clutch Cable
19 747-1159 Idler Pulley Rod
20 754-0434 Belt: 4L x 58.16 Lg.
21 756-0405 Fl-Idler w/Flange 3.75" O.D.
22 756-0971 Outer Engine Pulley Half
23 756-0972 Inner Engine Pulley Half
24 756-1162 Input Pulley
25 786-0064A Idler Bracket
26 786-0186 Belt Keeper Brkt.
27 786-0187 Shift Cover Brkt.
28 786-0193 Idler Belt Keeper
29 634-0106 RH Wheel Ass’y Comp. 16.0 x 4.0
634-0107 LH Wheel Ass’y Comp. 16.0 x 4.0
734-0808 Tire Only 16.0 x 4.0
30 634-0108 Wheel Rim Ass’y Comp.
31 734-0255 Air Valve
32 711-1017 Clevis Pin
33 714-0104 Internal Cotter Pin
34 710-0506 Hex Bolt 1/2-13 x 5.00" Lg.
35 712-3066 Hex Nut 1/2-13 Thd.
36 731-1595 Counterweight
37 736-0179 Fl-Wash. .510" I.D. x 1.0" O.D.
38 736-0921 L-Wash. 1/2" Lg.
39 710-0653 Hex Screw 1/4-20 x .375" Lg.
40 710-1017 Screw 1/4-14 x .625" Lg.
41 712-0392 Acorn Lock Nut
42 736-0463 Fl-Washer 1/4 x .620" Lg.
43 784-0158A Belt Cover
44 710-0805 Hex Bolt 5/16-18 x 1.50" Lg.
45 736-0242 Bell-Wash. .340 I.D. x .872 O.D.
46 712-3010 Nut:Hex 5/16-18
737-0298 Oil Drain Tube (Not Shown)
737-0132 End Cap (Not Shown)
REF.
NO. PART NO. DESCRIPTION
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Yard-Man
Green, the part number to order would be
700-xxxx-0665.
Yard-Man Green: 0665
Yard-Man Yellow: 0674
Powder Black: 0637
