8
CAUTION: Do not over tighten locknut as it will cause bearing damage in the rake tine wheel
hub. Rake tine wheel should spin freely. Assemble opposite side.
Make certain that the three rake tine wheels on opposite side are positioned as shown in
figure 10. All rake tine tips should rotate towards center in same direction.
