Yard Tuff SP-38 - Page 16

Page of 17
16
For replacement parts and technical questions, please call 1-952-938-5222.
Part No
Description
Qty.
Part No
Description
Qty.
1
Hopper Rope
1
40
Connecting Rod
1
2
Vinyl Cap
2
41
Hex Bolt M6x12
2
3
Hopper Frame Tube (Rear)
2
42
Dust Cover Retainer
2
4
Bag Frame Strap
1
43
Inside Star Washer
2
5
Hopper Support Rod
2
44
Brush Shaft Bushing
2
6
Hopper Bag
1
45
Spacer Bushing
2
7
Lower Hopper Frame Tube (L.H.)
1
46
Spacer for Axle
2
8
Upper Hopper Frame Tube (L.H.)
1
47
Plastic Bolt
4
9
Hex Bolt M8x16
5
48
Star Washer Ø5
6
10
Angle Bracket
1
49
Clevis Pin C
2
11
Bag Arm Tube
2
50
End Plate (L.H.)
1
12
Lower Hopper Frame Tube (R.H.)
1
51
Special Washer
2
13
Hex Bolt M8x40
2
52
Bushing
2
14
Upper Hopper Frame Tube (R.H.)
1
53
Retaining Ring Ø15
4
15
Height Adjust Gripe
1
54
Adj. Washer A
4
16
Lock Nut M6
18
55
Adj. Washer C
2
17
Height Adjustment Handle
1
56
Dowel Pin (Drive)
2
18
Carriage Bolt M8x30
1
57
Pinion Gear (L.H.)
1
19
Brush Shaft
1
58
Adj. Washer B
2
20
Brush
4
59
Clevis Pin D
2
21
Wrapper
1
60
Wheel & Tire Assembly
2
22
End Plate (R.H.)
1
61
Wheel Bushing
4
23
Pinion Gear (R.H.)
1
62
Hex Bolt M8x65
2
24
Dust Cover Assembly
2
63
Hex Bolt M8x50
2
25
Height Adjustment Tube Assembly
1
64
Hub Cap
2
26
Clevis Pin Ø6x37
4
65
Hex Bolt M6x35
4
27
Wing Knob
1
66
Spacer Bushing for Height Adj.Strap
1
28
Washer
2
67
Nylon Lock Nut M10
2
29
Hex Lock Nut M8
12
68
Hex Bolt M5x25
6
30
Slotted Pan Head Screw M5x12
14
69
Big Flat Washer Ø8
1
31
Retainer Brush
6
70
Hex Bolt M6x20
12
32
Height Adjustment Strap
1
71
Retainer Brush
12
33
Hitch Tube (R.H)
1
72
Hitch Pin
1
34
Hitch Bracket
1
73
Cotter Bearing
2
35
Hitch Bracket (Straight)
1
74
R Pin Ø3
5
36
Hitch Tube (L.H.)
1
75
R Pin Ø2
4
37
Big Flat Washer Ø10
4
76
Big Flat Washer
1
38
Hex Bolt M10x85
2
77
Hex Bolt M8×20
1
39
Nylon Lock Nut M5
20
