Yardian YDN1602 - Disconnect and Label Wires; Remove Old Controller

Disconnect your old controller and remove sprinkler wires. Adhere a numeric labeling
sticker to tag each associated wire.
Remove your old controller from the wall.
1
2
3
Zones
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
Exposed sprinkler wires with 24Vac could
generate an electric shock in wet location.
Please ask your retailer or contractor if
sprinkler accessories may be needed.
Electrical
Hazard
WARNING
