Yardian YDN1602 - Connect Sprinkler Wires

Connect sprinkler wires according to the
corresponding labels.
SN :
MAC :
YID :
AA00754F
<MAC Number>
<Serial Number>
Note: Please specify rain sensor
type (normally open or closed) in
the app if applicable.
Note: If you have a master valve,
we suggest to connect it to the last
zone and specify it in Yardian app.
12 Zones8 Zones
15
Step 2.
