Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
Y70229-1552
1pc. (2258)
Closer Block FSC 95.2 mm (3-3/4")
Y50229-2258
1pc. (2293)
Shelf Block FSC 829.6 mm (32-1/2")
Y50229-2292
4pc. (1552)
F/B Panel FSC 762 mm (30")
Y50229-2261
Y50229-2263
Y70229-2282
Y70229-1147
1pc. (2261)
Gable Right Upright FSC 472.3 mm (18-5/8")
Y50229-2262
4pc. (1147)
F/B Panel FSC 762 mm (30")
1pc. (2262)
Gable Left Upright FSC 472.3 mm (18-5/8")
1pc. (2263)
Gable End Vent - Top FSC 705 mm (27-3/4")
1pc. (2282)
Gable End Vent FSC 685.8 mm (27")
2pc. (2254)
Window Top Trim FSC 688.9 mm (27-1/8")
1pc. (2260)
Shelf Side FSC 546.1 mm (21-1/2")
1pc. (2255)
Door Trim Top FSC 688.9 mm (27-1/8")
Y50229-2255
Y50229-2254
Y50229-2260
Y50229-2257
2pc. (2257)
Upper Shelf FSC 2189.4 mm (86-3/16")
Y70229-2265
2pc. (2264)
Vent Trim Side FSC 309.8 mm (12-3/16")
2pc. (2265)
Peak Spacer FSC 177.8 mm (7")
2pc. (2259)
Side Shelf Gusset FSC 536.6 mm (21-1/8")
1pc. (2256)
Window Block FSC 114.3 mm (4-1/2")
Y50229-2256
Y50229-2259
Y50229-2264
Y50229-2293
1pc. (2292)
Shelf Back Support FSC 1524 mm (60")
Y50229-2290
4pc. (2290)
Joist FSC 346.1 mm (13-5/8")
Y50229-2291
2pc. (2291)
Side Joist FSC 381 mm (15")
