Step 24: Attach Door Closer
Part 2
F24.3
Components
2 x 12 mm Ring
1 x Top Tube Bracket
1 x 130
°
Angle Bracket
1 x Bottom Tube Bracket
1 x Short Pin
1 x Long Pin
1 x Tube
12 mm Ring
