Yardistry YM12863 - Page 12

12 support@yardistrystructures.com
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
Part Identification ( )
55pc.
Pan Screw (
Yellow
) #10 x 1-1/4"
Y06491-711
S12
138pc.
Pan Screw (
Black
) #10 x 1-1/4"
Y06418-711
1pc.
Robertson Driver #2 x 2"
Y00400-005
1pc.
Drill Bit 1/8"
Y00400-002
S5
80pc.
Pan Screw #8 x 1/2"
Y06418-502
8pc.
1/4" Lock Washer
Y05318-200
LW1
32pc.
Wood Screw #8 x 2-1/2in
Y06091-522
S3
33pc.
Wood Screw #7 x 3/4"
Y06018-003
S39
8pc.
1/4" Flat Washer
Y05118-201
FW1
95pc.
Wood Screw #8 x 1-1/4"
Y06091-511
S14
49pc.
Wood Screw #8 x 2"
Y06091-520
S11
79pc.
Wood Screw #8 x 3"
Y06091-530
S4
8pc.
1/4" T-Nut
Y08518-200
TN1
64pc.
Wood Screw #10 x 4"
Y06091-740
S24
16pc.
Truss Screw #8 x 7/8"
Y06418-505
S0
8pc.
Hex Bolt
1/4 x 3"
Y07718-230
H12
S10
26pc.
Pan Screw #8 x 1"
Y06418-510
