41 support@yardistrystructures.com
F3.33
Note: UV
Coating to the
outside of the
frame
F3.34
F3.35
Components
1 x Gable Center Tall
Top Tape
Bottom Tape
Note: Notches
always at the
bottom right of
each panel from
the outside
Gable Center
Tall
Gable Center
Tall
Outside View
(2243)
Remove lm from both sides of Gable Center Tall.
Outside View
Step 3: End Wall Assembly
Part 10
Top Tape
Bottom Tape
Refer to pages 17 and 18 and apply top and
bottom tape to Gable Center Tall.
