Yardistry YM12863 - Page 57

57 support@yardistrystructures.com
Step 6: Frame Assembly
Part 7
Hardware
24 x #10 x 1-1/4” Pan Screw (yellow)
Components
12 x Corner Bracket
S12
S12
x 2
per bracket
(yellow)
F6.22
F6.23
Corner
Bracket
#10 X 1-1/4” Pan Screws
Connects Corner Bracket to bottom
4 corners.
F6.24
#10 X 1-1/4” Pan Screws
Connects Corner Bracket to bottom
4 corners.
Corner
Bracket
S12
x 2
per bracket
(yellow)
(2244)
(2250)
