Yardistry YM12863 - Page 72

72 support@yardistrystructures.com
PC Support
Brace A
Step 12: Install Supports
Hardware
24 x #8 x 1” Pan Screw (black)
S10
Components
2 x PC Support Brace A
4 x PC Support Brace B
S12
x 24
PC Support
Brace B
PC Support
Brace A
PC Support
Brace B
PC Support
Brace B
F12.2
F12.1
Note: This edge
is tight to Roof PC
Panel A and Roof
PC Panel B
Parts removed
for clarity
Roof PC
Panel
PC Support
Brace
Side View
F12.3
